Description
Key Features
Optics
-
Day/night functionality
-
Smart IR, up to 30m (98ft) IR distance
-
3D DNR (Digital Noise Reduction)
Compression
-
Ultra 265, H.265, H.264, MJPEG
-
ROI (Region of Interest)
Network
-
ONVIF Conformance
Structure
-
Support PoE power supply
-
Wide temperature range: -30°C ~ 60°C (-22°F ~ 140°F)
-
Wide voltage range of ±25%
-
IP67
-
3-Axis
Specifications
|
Specifications SC-3253-IS-F28 |
SC-3253-IS-F40 |
||||
|
Camera |
|||||
|
Sensor |
1/2.7", 5.0 megapixel, progressive scan, CMOS |
||||
|
Lens |
2.8mm@F2.0 |
4.0mm@F2.0 |
|||
|
DORI Distance |
Lens (mm) |
Detect (m) |
Observe (m) |
Recognize (m) |
Identify (m) |
|
2.8 |
42 |
16.8 |
8.4 |
4.2 |
|
|
4.0 |
60 |
24 |
12 |
6 |
|
|
Angle of view (H) |
105.3° |
79.7° |
|||
|
Angle of View (V) |
69.5° |
51.8° |
|||
|
Angle of View (O) |
136.9° |
98.0° |
|||
|
Adjustment angle |
Pan: 0° ~ 360° |
Tilt: 0° ~ 80° |
Rotate: 0° ~ 360° |
||
|
Shutter |
Auto/Manual, 1 ~ 1/100000s |
||||
|
Min. Illumination |
Colour: 0.01Lux (F2.0, AGC ON) 0Lux with IR |
||||
|
Digital noise reduction |
2D/3D DNR |
||||
|
Day/Night |
IR-cut filter with auto switch (ICR) |
||||
|
S/N |
>52dB |
||||
|
IR Range |
Up to 30m (98ft) IR range |
||||
|
Wavelength |
850nm |
||||
|
IR On/Off Control |
Auto/Manual |
||||
|
Defog |
Digital Defog |
||||
|
WDR |
DWDR |
||||
|
Video |
|||||
|
Max. Resolution |
2592*1944 |
||||
|
Video Compression |
Ultra 265, H.265, H.264, MJPEG |
||||
|
H.264 code profile |
Baseline profile, Main Profile |
||||
|
Frame Rate |
Main Stream: 5MP (2592*1944), Max 20fps; Sub Stream:720P (1280*720), Max 20fps |
||||
|
Video Bit Rate |
128 Kbps~16 Mbps |
||||
|
OSD |
Up to 4 OSDs |
||||
|
Privacy Mask |
Up to 4 areas |
||||
|
ROI |
Up to 2 areas |
||||
|
Motion Detection |
Up to 4 areas |
||||
|
Image |
|||||
|
White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
||||
|
Digital noise reduction |
2D/3D DNR |
||||
|
Smart IR |
Support |
||||
|
Flip |
Normal/Vertical/Horizontal/180° |
||||
|
Dewarping |
NA |
||||
|
HLC |
Supported |
||||
|
BLC |
Supported |
