Description
| CAMERA | |
| Image Sensor | 8.29 megapixel progressive scan CMOS |
| Signal System | PAL/NTSC |
| Frame Rate | TVI: 8MP@12.5fps, 8MP@15fps, 5MP@20fps, 4MP@25fps, 4MP@30fps, 2MP@25fps, 2MP@30fps |
| CVI: 8MP@12.5fps, 8MP@15fps | |
| AHD: 5MP@20fps | |
| CVBS: 960H P/N | |
| Min. Illumination | Color: 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR |
| Lens | 2.7 mm to 13.5 mm motorized vari-focal lens |
| Shutter Speed | PAL: 1/12.5 s to 1/50,000 s |
| NTSC: 1/15 s to 1/50,000 s | |
| Day & Night | ICR cut filter |
| Synchronization | Internal |
| Resolution | 3840 (H) × 2160 (V) |
| Angle Adjustment (Bracket) | Pan: 0° to 360°, Tilt:0° to 90°, Rotate: 0° to 360° |
| Lens Mount | Φ 14 |
| DWDR (Digital Wide Dynamic) | 105 dB |
| MENU | |
| AGC | Yes |
| D/N Mode | Color/ BW/ Auto |
| White Balance | Auto/Manual |
| BLC | Yes |
| Function | Brightness,Sharpness,Digital Noise Reduction, Mirror, Smart IR |
| GENERAL | |
| Working Temperature | -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation) |
| /Humidity | |
| Power Supply | 9.6 VDC to 14.4 VDC; 19.2 VAC to 28.8 VAC |
| Power Consumption | Max. 10.8 W |
| Weather Proof Ratings | IP67 |
| IR Range | Up to 263ft(80 m) |
| Dimensions | 84.5 mm × 92 mm × 255.1 mm (3.33" × 3.62" × 10") |
| Weight | Approx. 695 g (1.53 lb.) |
